Electric Hand Shearing Machine China

The electric shearing machine is a new type of energy-saving mechanical shearing machine. It adopts a cycloidal pinwheel reducer to drive and adopts a convenient electric appliance for electric operation. It has low noise and convenient operation and maintenance. The structure is reasonable, the shear is automatically reset, and the footswitch device is provided. The pedal is light and free. Cutting quality: the incision is straight, the sideline is straight, and there is no burr, which achieves the precision shearing effect. Electric Hand Shearing Machine

Power saving, precision cutting, easy to operate, economical and practical, the price is lower than the price of hydraulic shearing machine, but the electric shearing machine has high working efficiency. Before using the electric shearing machine, keep the machine in balance, please always fill the oil, keep the oil cup oily, so as to lubricate, and work lightly. Generally used in housewares, electrical appliances, color tile, and sheet cutting.

Electric Shear Machine Description

1. An electric shearing machine is used for the shear sheet metal in line, metal materials should have a tensile strength of less than 450 N/mm2, and non-metallic materials including rubber, and plastics, when cut hot plate temperature should be below 50 °C, The machine can make only intermittent shear in full load, if the tensile strength is higher, the cutting thickness should be reduced.

2. Electric shearing machine is applicable to uncoiling, leveling, shearing, workshop of production line for plate processing

3. The electric shearing machine base is steel-welding, the structure is compact, good rigidity.

4. Track of blade movement is precision casting copper, less friction

5. Upper guide can adjust until achieving a good shear section, below blade can adjust via welding screw make the cutting mouth smooth

6. Feeding devices use spring pressure, the clamps have mat pieces, the pressure force is big, and not easy to damage the sheet metal surface.

7. Electric shearing machine uses a completely independent closed gearbox transmission system, move directly connection, compact structure, gear have good lubrication, low noise, and long life.

8. Electric shearing machine equipped with pneumatic clutch device.

Electric Hand Shearing Machine Main Features

1. The whole machine body uses the integral weld structure, ensuring the high strength and good rigidity of the machine.

2. The machine hasn’t the clutch and the flywheel. It shears the sheet metal directly driven by the magnetic brake motor. This reduces the idle time of the motor and saves energy. Electric Hand Shearing Machine

3.The structure of the machine is simple, easy to operate, and low consumption.

4.Shearing blade uses 6Cr2Si material, ensuring good performance and long performance life.
