Sobre

Acerca de la maquinaria HARSLE

Reproducir vídeo

La serie de corte es una parte inevitable del procesamiento de chapa, desde el pretratamiento de la chapa hasta el embellecimiento del producto terminado, lo que requiere la cooperación de máquinas de corte. HARSLE no solo ofrece cizallas de compuerta convencionales, cizallas de péndulo y cizallas eléctricas, sino que también puede equiparse con varios sistemas inteligentes, y la máquina misma puede equiparse con una variedad de accesorios, como alimentación frontal y tarimas traseras, para aumentar la eficiencia de la máquina. . Las cuchillas superior e inferior tienen cuatro cuchillas cada una y están hechas de 6CrW2Si para un corte preciso y una larga vida útil.

100+

Países alcanzados

1.5K +

Clientes atendidos

15+

Años de experiencia

Historia de desarrollo

2006

Estableció Nanjing HARSLE Machine Tool Co.,Ltd., dedicada a la producción, venta y mantenimiento de maquinaria para láminas de metal, como dobladoras, cizallas, punzonadoras y prensas hidráulicas.



2009

Proporcionar a los clientes un conjunto completo de máquinas para el procesamiento de puertas metálicas, el procesamiento de fregaderos metálicos y otras líneas de producción, y hemos firmado acuerdos de cooperación con agentes en el extranjero para brindarles a nuestros clientes mejores servicios.



2013

Las ventas anuales de comercio interior y exterior han superado los 10 millones de dólares. Cada vez son más los clientes que confían en nosotros y trabajan con nosotros, y además les hemos proporcionado los productos más adecuados. Con un fuerte volumen de exportación y excelentes comentarios de los clientes, Made-in-China.com lo seleccionó como proveedor certificado.

2017

Los principales productos de nuestra empresa: plegadora, cizalla y prensa hidráulica han obtenido el certificado de patente de modelo de utilidad certificado por la Oficina Estatal de Propiedad Intelectual. En los años siguientes, la plegadora CNC producida por nuestra empresa independiente obtuvo el certificado de patente de diseño de apariencia certificado por la Oficina Estatal de Propiedad Intelectual.

2019

Las prensas plegadoras e hidráulicas producidas por HARSLE han obtenido la certificación CE. Participamos en la 6ª Exposición BLECH de India en el mismo año y atrajo a muchos clientes extranjeros para realizar pedidos en el acto con máquinas de alta calidad y explicaciones profesionales.

2020

La punzonadora y la cizalla producidas por nuestra empresa han obtenido sucesivamente la certificación CE. En el mismo año, la empresa participó en la exposición de Dubái y aprobó la certificación del sistema de calidad ISO9001:2015.

Our Services

Sobre

Phone(free)

365 días al año, 7x24 horas a la semana y soporte de servicio de la línea telefónica de la empresa (+ 86-25-56200956).

Sobre

E-mail(free)

E-mail service support is available 24 hours per day, 365 days per year. E-mail: support@harsle.com

Sobre

Teamviewer(free)

The company established a technical support and response center, set up a dedicated person to carry out 7x24 hours on duty.

Sobre

On Site(charge)

Cuando sea necesario, la empresa enviará ingenieros técnicos experimentados al sitio para brindar servicios a los usuarios.

WHY CHOOSE HARSLE

Fabrication Equipment

HARSLE has both experienced senior engineers and innovative young engineers, all of them are committed to building better machines.

Sobre
Sobre
Sobre
Sobre
Sobre
Sobre

Vídeo de la máquina de corte

El programa de video siempre es lo mejor para ayudar a los clientes a elegir la cizalla de chapa adecuada, por lo que HARSLE se esfuerza por crear los videos más atractivos y útiles para que aprenda más sobre los detalles de nuestra cizalla hidráulica de una mejor manera.

Máquina de corte de metal HARSLE con E200PS

Cizalla guillotina con ELGO P40

Cortadora de metales QC12Y/K-4x3200

Controlador de pantalla táctil ELGO P40T

Máquina cortadora de guillotina con DAC-310T

Cizalla guillotina con ELGO P40T

HARSLE CE Certificate

In line with EU CE standards, the quality of the machine is guaranteed

CE-Certificate
MOSTRAR LOS MIEMBROS DE NUESTRA EMPRESA

NUESTRO EQUIPO

Las ventas de HARSLE son experimentadas y amigables, así que no dude en contactarnos cuando tenga preguntas sobre la máquina.

Sobre

División de flexión

Ivy Zhang
Sobre

División de esquila

Sissi Zhang
Sobre

División de punzonado

Wendy Xu
Sobre

Froming Division

Grace Guo
Sobre

División de puertas

Jimmy Chen
Sobre

División láser

Sandy Xue

Voz de
Clientes

Esto es lo que dicen los clientes de todo el mundo sobre nuestra cizalla.

Contamos con un excelente equipo técnico de posventa, que puede ser atendido de acuerdo con los requisitos de los clientes.

Frequently Asked Questions

If you have more questions, please click the button below to view.

Preparing steps before using hydraulic shearing machine

Please refer to the following page to get more details:
https://www.harsle.com/Preparing-steps-before-starting-hydraulic-shearing-machine-id6434116.html

What are the Advantages of Shearing Machine Blade For Cutting Stainless Steel?

Plate shears are machines that use one blade to make reciprocating linear motion relative to another blade to cut plates. By means of the moving upper blade and fixed lower blade, the Shearing Machine Blade For Cutting Stainless Steel with reasonable blade clearance is used to apply a shear force to metal plates of various thicknesses. The plates are broken and separated according to the required size. Plate shears are forging machinery, whose primary function is in the metal processing industry. The products are widely used in aviation, light industry, metallurgy, chemical industry, construction, shipbuilding, automobile, electric power, electrical appliances, decoration, and other industries to provide special machinery and complete sets of equipment.

The company produces high, medium, and low-speed plastic crushing and granulation blades, which are made of a variety of alloy materials, including all steel and embedded steel (high-speed steel, cemented carbide, etc.), with different specifications and sizes, including strip and cylindrical; There are dry cutting and water cutting blades, which are suitable for high and low-temperature cutting and shearing machine blades. The company also produces blades for peripheral equipment of injection molding machines, which has the advantages of high cutting efficiency, low noise, and vibration, etc.

What is the development trend of the blade of the shearing machine?

1. Modernization of materials
Among the new trends in the development of plate shear blades, the important thing is the modernization of materials. Many new materials in the new era have begun to become the basic materials for the production of plate shear blades, such as 12CrMoV and 6CrW2Si, which are newly developed new materials. Since they are used as the material of plate shear blades, the performance of plate shear blades has also been greatly improved, and there are more and more kinds of materials that can be used for cutting So that the plate shearing machine has been rapidly popularized.

2. Diversification of uses
Nowadays, there are more and more uses of plate shears. Before, most of the blades of plate shears we saw were used for ordinary and simple plate cutting. Now, many new material blades are used for more and more purposes. For example, we can see the shadow of this new material blade plate shears in factories making stainless steel kitchenware and furniture, This wide application makes the application of plate shears more diversified.

3. Simplification of form
Compared with the previous plate shears, the current plate shears also look much simpler, especially the plate shears made of some new materials are more lightweight and exquisite. Such simple and exquisite blades can also make the plate shears more convenient for application in more industries. In the later production industry of plate shear blades, the refined and simplified blade is also a general trend in the development of plate shear blades.

How to adjust the blade of the shearing machine

There are many kinds of plate shears and different adjustment methods, so no matter what model, it is not the blade of Nanjing shear blades that can be adjusted by anyone. You can ask a professional master to debug, otherwise, you may hurt your body if you don't say it accurately. Before adjusting the clearance, we need to check whether the shear blade is repaired or adjusted after changing the blades. We should carefully adjust them step by step according to the type and thickness of materials.

First, adjust the screw in the stop on the workbench. After rotating the screw, the workbench can move back and forth, so as to adjust the gap between the upper and lower blades. The indicating machine installed on the column can read the movement of the worktable. When the blade gap is too large, the cutting part of the plate will be deformed and burred; If the blade clearance is too small, the plate will be crushed, and the machine tool will be damaged in serious cases. Therefore, it is very important to adjust the clearance of the blade of the plate shear.

How to adjust the blade gap of shearing machine?

Please refer to the following page to get more details:
https://www.harsle.com/How-to-adjust-the-blade-gap-of-shearing-machine-id3083071.html

What are the features of a shearing machine?

HARSLE guillotine machine cutter supplier will introduce you what is shearing machine. A shearing machine is a machine that uses one blade for reciprocating linear motion shear plate with another blade. It's a used blade and a fixed blade, using a reasonable blade, to apply shear force to the metal sheets of various thicknesses, and to make the board break apart at the size of the required size. Shearing machine is a kind of forging machinery, the main function is metal processing industry. The products are widely used in aviation, light industry, metallurgy, chemical industry, construction, ship, automobile, electric power, electric appliance, decoration and other industries to provide the special machinery and complete equipment.

Special plate shears
Cooperate with other equipment for special purpose:
1. Cold bending molding line shears: for example, the special shears that are used in the production lines such as the cold bending line of the automobile longitudinal beam, the side baffle plate production line, the color steel plate molding line, etc.;
2. Shearing machine for steel structure production line: it is mainly used for cutting process of Angle steel and h-beam automatic production line;
3. Plate shearing machine: it is used for high speed shearing machine designed to meet the requirement of fast cutting of the production line, and the thick plate line is mostly hydraulic high-speed shearing machine, and the thin plate line is equipped with pneumatic shearing machine. High-speed online with flying shears, continuous production, high efficiency.

Diagonal cutting machine
Shearing machine of upper and lower blade into a point of view, generally on the blade is tilted, the slope Angle is commonly 1 ° to 6 °. The shear of the diagonal shear is smaller than the flat blade, so the power of the motor and the weight of the whole machine is reduced, and the most practical application, the shearing machine is producing these kind of shears.

Flat blade shears
The shear quality is good, the distortion is small, but the shear force is large and the energy consumption is large. More mechanical transmission. The two blades of the shearing machine are parallel to each other, and are often used in the hot shearing of the rolling mill and the slab. According to its shear mode can be divided into upper cut and lower cut type.

Multi-purpose shears
1. Combined punching and shearing machine: the shear of the plate can be finished, and the profile can be cut.
2. Plate bending and shearing machine: the process of cutting and bending can be accomplished on the same machine.

What are the types of shearing machines?

Special shearing machine
Use with other equipment to complete special purposes:
1. Shearing machine for cold bending forming line: such as special shearing machine configured on production lines such as automobile longitudinal beam cold bending line, carriage side baffle production line, color steel plate forming line, etc.;
2. Shearing machine for steel structure production line: it is mostly used for angle steel and H-beam automatic production line to complete the shearing process;
3. Plate opening and leveling line shearing machine: It is a high-speed shearing machine designed to meet the requirements of high-speed cutting of the production line. It is used on the plate uncoiling and leveling line. The thick plate line is mostly hydraulic high-speed shearing machine, and the thin plate line is more Equipped with pneumatic shearing machine; high-speed line is equipped with flying shearing machine, continuous production and high efficiency.

Inclined blade shears
The upper and lower blades of the shearing machine are at an angle. Generally, the upper blade is inclined, and the inclination angle is generally 1° to 6°. The shearing force of the inclined blade shearing machine is smaller than that of the flat blade shearing machine, so the motor power and the weight of the whole machine are greatly reduced, and the practical application is the most.

Flat blade shears
The shearing quality is good, the distortion is small, but the shearing force is large and the energy consumption is large. More mechanical transmission. The upper and lower cutting edges of the shearing machine are parallel to each other, and are often used in hot-cutting billets and slabs in rolling mills.

Multipurpose shears
1. Ironworker machine: it can complete the shearing of the sheet and the profile, which is mostly used for the blanking process;
2. Sheet metal bending and shearing machine: that is, two processes of cutting and bending can be completed on the same machine.

What is a guillotine shear?

The gate shear adopts frame structure and all steel welding; Four corner octahedral right angle guide rail, high precision, good rigidity, and hydraulic preloading. The hydraulic system adopts two-way cartridge integrated valve; The whole system adopts; In addition, it can be equipped with stroke digital display, photoelectric protection device and mobile worktable (convenient for replacing molds). The gate plate shear has the double action function of upper sliding block and lower hydraulic pad. The working pressure stroke can be adjusted according to the process requirements within the specified range. It is easy to operate and centrally controlled by buttons.

Exhibition Style

Since the company was founded, HARSLE has participated in various national and international exhibitions every year
